SuperCatch, filling indicator, up/down, temperature and rip functions
5 year warranty
Up to 1500 hours of use from one charge
The DepthSensor is an invaluable tool in trawling and Purse Seine fisheries, providing accurate information of the sinking speed and depth, which enables the skipper to decide when to start trawling/pursing
Negligible operation cost and long lifetime
Up to 700 hours of operating time
· Functions in the new SS4 DS
DISTANCE: Door distance, bottom & pelagic trawl
DEPTH: Door depth
TEMPERATURE: Sea water temperature
TENSION: Tension in trawl wires or sweeps
ANGLE: Door angle (roll & pitch)
STABILITY: Door stability (ScanFactor)
Provides accurate distance between clump(s) and both doors on twin and triple trawls
Multifunctional: Distance, Angle, Depth, Temperature, Tension and Bottom contact
Robust construction and plastic protects against damage and wear
Up to 700 hours operation time on clump Quick charging
Detects fish and shrimp not visible on the vessel’s echo sounder
Measures the height of the trawl opening, the height from the headline to bottom, and bottom contact or clearance
Enables skippers to optimize the trawl geometry
Configurable with diff. ranges on down- and/or upward
Includes two batteries
Advanced echo sounder showing fish influx and volume
Measures the height of the trawl opening, whether the trawl is on the bottom and the distance between the trawl and the bottom
Used in pelagic, bottom trawling as well as Danish/Scottish Seine
Ideal to pair with DoorSensors for showing a simplified trawl geometry
Two functions: TrawlSpeed and Symmetry
The TrawlSpeed function measures the speed of the waterflow into the trawl opening
The Symmetry function measures the side currents into the opening
The sensor is used to assure optimal towing speed and trawl symmetry to reduce fuel costs and loss of catch
Used to fish more efficiently with grid Measures the grid’s angle, indicating the catch volume
Shows if the waterflow through the grid is blocked, resulting in loss of catch
Applicable for bottom and pelagic trawls
New charging and battery technology delivers rapid charging and the option to activate additional sensor functions.
QBC-X1 is a configuration and test unit compatible with all Scanmar sensors, except the TrawlEye, and has several useful features
Designed for Trawlers
Scanmar’s trawl hydrophones are developed in close cooperation with more than a thousand of fishing vessels, and are specifically designed for trawler applications.
Noise immunity
The narrow vertical beam greatly improves the immunity to propeller noise, while the wide horizon-tal coverage simplifies operation
Two Variations
There are two types of mounting kit for Door Sensors: one for the traditional HC4 Distance Sensors and one for the new SS4 Door Sensors.
Anti Corrosion
The holders are solidly constructed of stainless steel, which is surface-treated to prevent corrosion.
The new spider graph feature is one that skippers are likely to quickly become dependent on.Even the most seasoned skipper can be overwhelmed with keeping track of multiple sets of sensor data at the same time as he is monitoring all the other practical aspects of the haul.
